Capacitive, ceramic pressure sensor
Application
Pressure sensor for use in the pressure measurement of liquidand gaseous media.
Your benefits
Dry capacitive ceramic sensor with ultrapure (99.9 %) Al2O3 ceramic
• High overload resistance
• Very good long-term stability
• High corrosion resistance
• Digital/analog signal output (SPI, UART, U)
• Measuring ranges from 0 to 0.1 bar (0 to 1.5 psi) to 0 to 40 bar (0 to 580 psi)
• Optional temperature output, switch output
